Home lift without shaft enclosure Aluminum frame with glass

Application and chief introduction

Hydraulic home elevators are solutions commonly found in various residential settings. These elevators are often used in luxury homes and villas, enhancing property value and overall livability. Hydraulic elevators can also be featured in small apartment buildings, providing accessibility to tenants. In some cases, they are installed in private offices that occupy multiple levels, facilitating easy movement for staff and visitors. Overall, hydraulic home elevators cater to diverse needs and are suitable for any setting requiring efficient vertical transportation within a residential or low-rise commercial environment.

Basic feature and advantage

Flexible size designing

The size of the hydraulic household elevator cabin can be flexibly designed, and the customizable size can adapt to the installation space on the construction site (such as stairwells, narrow corridors) without affecting the structural integrity. Compact configuration suitable for different architectural styles

Small shaft designnig

The hydraulic home lift can be tailored to fit into extremely tight spaces, only minimal structural modifications are required: no machine room is needed, only a load-bearing wall is needed. High space utilization rate up to 60%, which can reduce footprint greatly

Pitless installation

Hydraulic home lifts offer the advantage of providing pitless installation. The requirements for civil engineering structures are relatively low and can be installed without pits. Only one load-bearing wall is needed for installation.

Overhead room height lower can be lower than traction elevator's requested

The hydraulic home lift can run at the minimum vertical clearance in 2500mm ceiling height. It does not require a motor room or machine room. Suitable for low ceiling environments, preserving the original architectural aesthetics.

Easy and low cost maintenance

Simple hydraulic system and mechnical system can make sure the lift run smoothly. Energy-efficient pumps and rare component replacements ensure cost-effective operation‌. Furthermore, hydraulic lifts require less frequent and extensive maintenance compared to traction elevators, resulting in lower maintenance fees. There are low maintenance cost and easy operation for hydraulic home lift, which can provide both economic savings and operational convenience.

Production details explanation

Lift structure

We use China's national standard steel as the skeleton and surface material for our lifts, with each raw material certified by its supplier. The entire system has obtained CE certification after rigorous long-term testing of lab spare parts and the entire lift system.

Hydraulic system

Tebo hydraulic system of hydraulic cargo lifts serves as its core loading mechanism, utilizing China's national standard accessory products. Notably, 80% of these accessories meet military standards, enabling us to export our products to countries such as the USA, Japan, and those in Europe.

Electric system

The intelligent electronic control system of the hydraulic home lift   has a user-friendly touch interface, real-time safety monitoring, such as overload alarm, emergency stop, and energy-saving operation. Programmable settings can adapt to home layout. Low voltage design ensures safety .

Finishes parts

The exterior decorations of hydraulic home elevator are made of high-strength stainless steel, tempered glass,providing hairline stainless steel or mirror stainless steel, corrosion-resistant and easy to clean. Modular design suitable for various household styles, with optional LED lighting. Fully enclosed structure waterproof and dustproof, suitable for indoor and outdoor use, supports personalized pattern and color customization

Landing doors

There are four types of landing doors for you to choose from:

1.Manual Swing Door: Generally, it is composed of a single-panel door with an aluminum frame and glass. It can open either on the right - hand side or the left - hand side.

2.Automatic Swing Door: This type of door operates automatically, providing convenient access. It swings open in a similar way to the manual swing door but without the need for manual operation.

3.Automatic Swing Door with Center Opening: This door automatically swings open from the center. With beautiful appearance and unique styles, facilitating the entry and exit of passengers or goods.

4. Automatic sliding door.

This kind of door can be made into pure stainless steel or stainless steel with glass material. You can also choose the center opening or side opening style based on different door opening size.

Landing doors pictures

Safety system

Emergency stop system

When meet emergency situation during the operation of the elevator, pressing the emergency stop button, the elevator will stop immediately.

Overload system

Tebo hydraulic lifts feature a crucial overloaded protecting system. This safeguard is designed to detect when the goods loaded surpass the standard capacity. As soon as this occurs, the lift promptly stops and emits a loud alarm. Resuming operation is only possible when the load is within the limit, protecting the equipment and preventing potential hazards.

Light Curtain

The infrared safety light curtain of the elevator uses a series of infrared rays to detect obstacles at the entrance. If someone reaching out and touching the light curtain, the elevator will immediately stop to prevent danger and accidental injury to people, ensuring reliable protection for users, pets, or objects during the operation.

UPS power

In the event of a power outage,the home elevator can descend through UPS power.Then self rescue can be achieved easily.

Door safety sensors

Tebo brand hydraulic cargo lifts utilize door safety sensors to guarantee safety. This means that each set of landing doors, cabin door is equipped with at least one door safety limit switch. The electrical diagram is designed in the form of a safety loop for the door sensors, ensuring that all doors must be securely closed for the lift to function. In the event that any door is forcibly opened, the lift will immediately stop. The lift can only operate normally when all cabin doors and landing doors of the cargo elevator are fully closed and securely latched.

Drawing/sketches of worksite and lift

The worksite's parameters should be collected

Lifts' basic parameters

Lifts' drawing showing

Other services of us

Warranty

Tebo company provides a comprehensive 24month warranty for all its equipment, starting from the date of elevator handover. The warranty covers a wide range of essential components, including the entire transmission system, all hydraulic devices (with oil hoses and nipples), electrical parts and equipment (such as elevator LOP/COP and display systems), and specially finished accessories like door handles, hinges, and locks. This ensures that our customers can rely on our products for a long time.

Delivery time

At Tebo factory, each hydraulic lift platform is finished the production within 14 working days, with standard models typically completed earlier, usually in less than 10 days.

After sales work

We offer comprehensive 24/7 online after-sales support to ensure that our clients receive prompt assistance whenever they encounter difficulties during the installation or operation of their lifts. Whether clients reach out via phone or email, our dedicated after-sales team guarantees a swift response within 20 minutes. We assign specialized after-sales personnel to cater to the unique needs of various projects. Our after-sales services encompass assisting with installations through videos and manuals, troubleshooting in the event of lift malfunctions, reminding clients to perform regular maintenance on their lifts, and more.
