ApplicationScenarios:
Backpack-model hydraulic home elevatorsare designed for modern families who are seeking to enhance the comfort andliving environment of their homes. They are particularly suitable forresidential settings such as villas and houses with limited spaces fortraditional elevators’ installations. These elevators can be installed inexisting elevator shafts areas without the need for extensive civil engineeringworks.
ProductFeatures:
1. SimpleInstallation: The installation process of backpack-style home elevators isrelatively straightforward, requiring minimal civil engineering working and especiallysuitable for existing elevator shaft area.
2. SpaceEfficiency: These elevators offer space efficiency by utilizing a compactdesigning which fits well within the constraints of home environments.
3. Safety andStability: With mature technology and comprehensive emergency protection settings, backpack-mode elevators provide a safe, smooth and comfortableup/down riding experience.
4. Low NoiseDesigning: The use of steel belts or steel ropes for lift's driving reducesmechanical stress and vibration on the car-rail structure, that's significantlylowering the noise during lift's up and down running.
Sizeand Model List:
Model | Stops | Capacity(kg) | Lifting height(mm) | Cabin size(mm) |
TB350-2 | 2 | 350 | 3500 | W1200*D1200*H2100 |
TB350-3 | 3 | 350 | 7000 | W1200*D1200*H2100 |
TB350-4 | 4 | 350 | 10500 | W1200*D1200*H2100 |
TB350-5 | 5 | 350 | 14000 | W1200*D1200*H2100 |
TB350-6 | 6 | 350 | 17500 | W1200*D1200*H2100 |
DetailedProduct Introduction:
Backpack-style hydraulic homeelevators utilize a single hydraulic cylinder on back side of cabin as the drivingsystem, which allows for a larger cabin size within limited space. Thestructure is highly integrated, and the elevator can be customized to fitvarious home environments. The low builds’ construction requirements, with onlya load-bearing wall needed and a top floor height of over 2600mm, make it anideal choice for homes with limited space. The elevator's hydraulic system isdesigned to prevent out-of-control speeds, ensuring a high safety coefficient. Overall,the elevator can be equipped with backup batteries for emergency lowering incase of power failure or system malfunctions.
